AD-Link AD-IN602-B (1 PER ROLL) — • UTP CAT6E 305m 0.56mm copper(Blue)

SKU KY-87681D097B6F · Unit: piece

• UTP CAT6E 305m 0.56mm copper(Blue)

Ask sales to confirm stock, configuration and compatibility.

Product description

• UTP CAT6E 305m 0.56mm copper(Blue) • InnerConductor thickness: 0.56mm(PURE COPPER) • Conductor size: 23AWG • Stretching Resistance: 400N (max) • Conductor material: BC • Impedance: 100±15%Ω at 1~250MHz • No. of Conductor: 4P • DC Resistance Imbalance: 72% • Insulation Material: HDPE • Working Capacitance(Max.): 5.4nF/100m • Jacket: ROSH PVC • Insulation Resistance: 10000MΩ.km • Shield: Unshielded Twisted Pairs • Operating Temperature: -40 °C -+70 °C • Filler: PE Cross • Insulation Jacket: 0.2mm Jacket • Jacket Thickness: 0.95-1.02mm
