AD-Link / Peripherals & accessories

AD-Link AD-OUSF601-C (1 PER ROLL) — • SFTP CAT6E OUTDOOR CABLE

SKU KY-13DC6D47B1B3 · Unit: piece

• SFTP CAT6E OUTDOOR CABLE · Cable

Ask sales to confirm stock, configuration and compatibility.

Product description

• SFTP CAT6E OUTDOOR CABLE • Conductor Material: CCA • Stretching Resistance: (max)450N • Conductor Size: 23AWG (0.5mm) • DC Resistance Imbalance: 2.50% • Conductor Structure: Solid • Insulation resistance：≥5000MΩ.km • Twisted Pair: 4PAIRS • Delay deviation: (max)45ns/100m • Inner Jacket: PVC • Operating Temperature: -40 °C -+70 °C • Inner Diameter: 6.0mm(±0.02mm) • Transmission Velocity: 66% • Outer diameter: 6.8mm(±0.2mm) • Braid: YES • Outer Jacket Material: HDPE • Insulation Material: PE • Insulation Diameter: 1.0mm(±0.02mm) • Insulation Thickness: 0.18mm • Shielded: AL Foil + Polyester Film • Impedance: 100±15%Ω at 1~250MHz
